Sony Ericsson Bluetooth HBH-IV840: instruction
Class: Headphones and Earphones
Type:
Manual for Sony Ericsson Bluetooth HBH-IV840
™
Bluetooth
Headset
HBH-IV840
This is the Internet version of the User's guide. © Print only for private use.
Contents
English ..............................................................2
Suomi .............................................................. 14
Русский .......................................................... 27
Čeština ............................................................ 41
Deutsch ........................................................... 54
Ελληνικά ......................................................... 67
Declaration of conformity .............................81
FCC statement ................................................82
1
This is the Internet version of the User's guide. © Print only for private use.
English
Charging....................................................... 6
Pairing the headset ..................................... 7
Turning on and off....................................... 9
Calling........................................................... 9
Resetting the headset ................................11
Troubleshooting ........................................ 13
Sony Ericsson HBH-IV840
This User guide is published by Sony Ericsson Mobile
Communications AB or its affiliated company, without any warranty.
Improvements and changes to this User guide necessitated by
typographical errors, inaccuracies of current information, or
improvements to programs and/or equipment, may be made by
Sony
Ericsson Mobile Communications AB or its affiliated company
at any time and without notice. Such changes will, however, be
incorporated into new editions of this User guide. All rights
reserved.
©Sony Ericsson Mobile Communications AB, 2007
Publication number: 1002-2628.1
Some of the services in this User guide are not supported by all
networks. This also applies to the GSM International Emergency
Number 112. Contact your network operator or service provider
if
you are in doubt whether you can use a particular service or not.
The Bluetooth word mark and logos are owned by the Bluetooth
SIG, Inc. and any use of such marks by Sony Ericsson is under
license.
This product is leadfree and halogenfree.
2
This is the Internet version of the User's guide. © Print only for private use.
Introduction
The Bluetooth™ Headset HBH-IV840 can be
connected to any device with Bluetooth wireless
technology that supports the handsfree or headset
profile. This User guide focuses on usage with
a Sony Ericsson mobile phone.
3
This is the Internet version of the User's guide. © Print only for private use.
Front overview
Charging
connector
Call handling
key
Indicator light
4
This is the Internet version of the User's guide. © Print only for private use.
Back overview
On/off key
Speaker
Microphone
5
This is the Internet version of the User's guide. © Print only for private use.
Charging
Before you use the HBH-IV840 for the first time,
charge it with the supplied charger until the indicator
light turns green. Full battery capacity will be achieved
after the headset has been charged and discharged
a couple of times.
To charge the headset
2 h
6
This is the Internet version of the User's guide. © Print only for private use.
Pairing the headset
Before you can use your Bluetooth headset with your
phone it has to be paired once to the phone. Follow the
instructions from your phone User guide on how to turn
on Bluetooth in the phone.
For phones that do not support auto pairing, see your
phone User guide on how to pair a Bluetooth device.
If required, the headset passcode is 0000.
Note: The headset switches off if you do not pair it with
the phone within 10 minutes.
To pair the headset with the phone
1
Turn on Bluetooth in the phone.
2
Turn on Bluetooth visibility in the phone. This
makes the phone visible to other Bluetooth devices.
3
Place the phone within 20 cm (8 inches) from the
headset.
4
Make sure the headset is turned off. Press and hold
down the power key for five seconds. Make sure
the
indicator light flashes red or green.
5
If the phone supports auto pairing, press Yes when
Add device? appears in your phone to complete
the
procedure. If not, see the phone User guide.
6
The headset beeps and flashes green when
successfully paired.
After you have added the headset to the phone, it will
automatically connect to the phone as soon as it is
turned on and within range.
7
This is the Internet version of the User's guide. © Print only for private use.
Putting on the headset
To put on the headset
1
Attach the ear plug to the headset.
2
Make sure you place the earpiece firmly in your ear.
Warning! Loud volume could damage your hearing.
8
This is the Internet version of the User's guide. © Print only for private use.
Turning on and off
To turn on the headset
• Press and hold down the on/off key for two seconds.
A beep is heard and the indicator light flashes green.
To turn off the headset
• Press and hold down the on/off key for two seconds.
A beep is heard and the indicator light is turned off.
Calling
When you have paired the headset with your phone, you
can make and receive calls as long as the headset is
turned on. For best performance the headset should be
within 5 metres (16.5 feet) of the phone. Solid objects
and walls in between and greater distance can affect the
sound. We recommend that you wear your headset on
the same side of your body as your phone.
To make a call
• Use the phone keys, and dial the number in the
same
way as you normally would with your phone.
The
call is automatically activated in the headset.
To end a call
• Press the call handling key.
To answer a call
• Press the call handling key.
9
This is the Internet version of the User's guide. © Print only for private use.
To reject a call
• Press and hold down the call handling key for two
seconds.
To redial a number
• Press the call handling key twice within a second.
Adjusting volume
To adjust speaker volume
• During a call, press the volume key on the phone.
Calling using voice commands
Voice commands can be useful when you are using
the headset. By creating voice commands you can,
for example, call someone by saying their name.
Note: To be able to use this function, you first have
to
activate voice control in your phone and record voice
commands. For more information on voice commands,
and if your phone supports it, see the phone User guide.
To make a call using voice commands
• Press the call handling key, wait for the ring signal
and say the command.
Transferring sound
To transfer the sound from the phone
to
the headset
• During a call on the phone, press the call handling
key. The sound is transferred to the headset.
10
This is the Internet version of the User's guide. © Print only for private use.
To transfer the sound from the headset to the
phone
See the phone User guide.
Resetting the headset
Reset the headset if it behaves unexpectedly.
To reset the headset
1
Enter pairing mode.
2
Simultaneously press the power key and the call
handling key until the indicator light is turned off.
For info on how to enter pairing mode, see
Pairing
the headset on page 7.
Battery
A battery that has been infrequently used, or a new one,
could have reduced capacity. It may need to be
recharged a number of times.
When the battery is too low, the indicator light flashes
red and you hear a low beep. If you do not charge the
headset, it automatically turns off.
To check the battery status
Press the power key once shortly.
• one green flash - the battery needs charging.
• two green flashes - the battery is medium full.
• three green flashes - the battery is fully charged.
11
This is the Internet version of the User's guide. © Print only for private use.
Removing the cover
To remove the cover
Regulatory information can be found under the cover.
Attaching the strap
12
This is the Internet version of the User's guide. © Print only for private use.
Troubleshooting
No connection between headset and phone
Make sure the headset is charged and within range
of the phone. Check or redo the Bluetooth settings
in the phone. Try to pair the headset again.
The headset is automatically turned off
• The battery is too low. The indicator light on
the
headset flashes red and you hear a low beep.
• When the headset is in pairing mode it will
automatically switch off if you do not add
it
to the phone within 10 minutes.
Unexpected behaviour
1
Connect the charger.
2
Disconnect the charger.
3
Reset the headset.
Redial does not work
If the call list in the phone is empty you cannot use
the redial function.
Voice commands
Make sure that voice commands are enabled and
recorded in your phone before you start using them.
13
